IP66 MW driver 5 years warranty 160LM/W 5050SMD 750W 800W Stadium Flood Light

  • Product Item:HL-SP9B-750W/800W
  • Category:High power high mast light
  • Views:903
  • Driver: MW or Inventronics
  • Efficiency:160LM/W
  • Defend grade: IP66
  • Warranty: 5 years
  • Product Manual:750W 800W High Power Sports Lighting IP66 160LM/W LED 5050SMD High Mast Stadium Flood Light with 5 years warranty
BASIC INFO

750W 800W IP66 outdoor lighting 5050SMD stadium flood light

Technical Data:

Power output 750 Watts / 800 Watts
LED chip Philips Lumileds 5050SMD
LED quantity 288PCS
Lighting efficiency 160LM/W
Lumens output 120,000LM
Color temperature 3000K / 4000K / 5000K / 5700K
CRI Ra>70
Driver
Meanwell or Inventronics driver
Input voltage
AC100-305V / 50-60Hz
Power factor >0.97
SPD 10KV
Beam angle 10° / 20° / 40° / 60° / 90° / asy.50°
Materials Die casting aluminum & optical PC lens
Finish color Black
Defend grade IP66
Working temperature -45 ~ 60°C
N.W. / G.W. 17.5KG / 19KG
Packing
1pc/carton, 56x66x29cm
Lifetime 50,000hours
Warranty 5 years
Certificates LVD,EMC,CE,RoHS,FCC,UKCA,PSE,SGS,ISO9001
Application Stadium,sports field,ski resort,square high mast,seaport,etc

Product Features:

250W / 500W / 750W  / 1000W / 1250W / 1500W available.


Application:

It can be widely used in stadium,sports field,square high mast,playground,tennis court,golf course,ski resort,seaport,airport,construction site,parking lot etc.


Installation instructions:
1. Non-specialist electricians please do not repair or modify this product without authorization;
2. Please turn off the power before installation;
3. Before installation, please check whether the voltage marked on the lamp is consistent with the input voltage to be connected;
4. In order to ensure the service life of the product, please do not use it in a place with strong acid mist;
5. Pay attention to shock protection during installation and transportation;
6. Before installation, ensure that the installation position can withstand 10 times the weight of the product, and install it in a flat place without vibration, no swing, no fire hazard;
7. If the lamp fails, please place the lamp in one place and send it back to the company for inspection and repair.
8. If the lamp body or wire is damaged, please stop using it immediately.

Our workshop:
We have 8 production lines at production department, including assembling, inspection and aging test lines.
Production ability: 20-25 working days for 500pcs LED stadium lights at common requirements.
Each Lamp must pass 24 hours aging test and high voltage (10KV) surge test before we make packing and make delivery.

Our Services:
1. For all your inquires about us or our products, we will reply you in detail within 24 hours;
2. Excellent lighting engineering team with designers of more than 12 years experience, offer professional advice and solutions for any of lighting case;
3. Supply your local technical or clearing support by our customers from EU market,USA,Mexico,Japan,Russia,Kazakhstan, Australia,South Africa, Zimbabwe,Vietnam, Thailand,Honduras,Uruguay, etc;
4. OEM & ODM supported;
5. Export seaports Shenzhen or Guangzhou;
6. Discount available for bulk order;
7. Components and materials such as LED chip brand, driver brand can be customized by your needs.

Payment Terms:
TT Bank Transfer, support 30% deposit and 70% before delivery;
L/C at sight, western union, order online of Made-in-china or Alibaba etc.
NO O/A.

Delivery time:
Samples and less than 50pcs in 5-10 working days;
200pcs in 10-15 working days;
500pcs in 25 working days.

About Shipping:
1.Samples sent by DHL, TNT, Fed EX, UPS, SF Express, Aramex etc and door to door, you may need to pay customs tax depends on your customs policy.

2.By air cargo or by sea shipping for bulky orders.
3.By truck or by railway to Asian countries and EU countries.

FAQ:
1. Are you factory supplier?
Yes, we are manufacturer of LED lamps since 2008, we have our own factory more than 6000SQM and more than 60 members. We are gold supplier from made-in-china since 2012 and from Alibaba since 2018 audit by SGS with on-line order supported,who always supply durable quality items and reliable after-sale service.


2. Do you supply OEM or ODM?
Yes, we can supply OEM and ODM service with favorable price, your brand and logo can be printed on each item. Customized toolings are also available by our mould workshop.


3. How long will it spend for our orders to be sent out?
It takes 10-15 days for samples at common requirements, and 20-25 days for big order such as 500pcs LED stadium lights.


4. What about your after-sales servie and warranty policy?
We offer 5 years warranty for this LED stadium lights, by supplying you the lamp parts or new replacements for free during the warranty period for any quality problem.
